EXSYS EX-1348HMV interface hub USB 2.0 Type-B

EXSYS EX-1348HMV interface hub USB 2.0 Type-B

The EX-1348HMV USB 2.0 to serial RS232/422/485 in a metal case, provides eight high performance 16C550-type UART compatible RS232, 422 or 485 serial ports. It is designed for PC, Notebooks or 19-inch rack to provide instant COM port expansion in a robust metal case through the USB 2.0 bus. With the easy installation you don’t need to open the computer system. With the USB cable EX-K1552V (2 meter) A-male to B-male you can fix the connector with screw. The cable can’t be disconnect any more by him self. Optional you can install the EX-1348HMV with the product EX-6099 (DIN-Rail-Kit) in a 19-inch rack. The EX-1348HMV has LED displays for operation functions and data communication.

- Interface: RS232 V.24, RS422 and RS485
- FIFO Buffer: 16C550 with 16Byte
- Data Bits: 7, 8 / Stop Bits: 1, 1.5, 2 / Parity: none, even, odd, space, mark
- Signal RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Signal RS-422: 4-wire (TXD+/-, RXD+/-) Fullduplex
- Signal RS-485: 2-wire and 4-wire (Data+/-, Data +/-) Halfduplex/Fullduplex
- Power from the USB Bus (Bus Power)
- Supports TX and RX Activity LED Indicators
