EXSYS EX-45368 interface cards/adapter Internal Serial

EXSYS EX-45368 interface cards/adapter Internal Serial

The EX-45368 PCI I/O-adapter provides eight high performance 16C1050-type UART compatible RS-232, 422 and 485 serial ports. By each port you can select independent the interface type. It is designed for PC, thin client or server to provide instant COM port expansion via the PCIe Bus. The card is fully PCIe Plug-and-Play compatible and there are no IRQ and I/O address configuration problems. The EX-45368 support RS-485 Auto Transceiver turn around by unique feature ATTATM hardware. It provides +5V and +12V via the pin 9 from the male connector for a POS System (Power over System). Also it’s included a Low Profile bracket for small computer case.

- Interface: 8 x RS-232 V.24, RS-422/485 - independent mode selection
- FIFO Buffer: 16C1050 with 256Byte
- ±15kV IEC1000-4-2 ESD Schutz for RS232 I/O's
- I/O addresses and Interrupt: Setting from the System BIOS with IRQ Sharing
- Data Bits: 5, 6, 7, 8 / Stop Bits: 1, 1.5, 2 / Parity: none, even, odd, space, mark
- Support ATTATM Auto Transmitter
- Support PCIe slot version 1.0 to 3.0
- Terminator RS-422/485 120 Ohm can be enable– and disable
- Signal RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Signal RS-422/485
- RS-422 - 4 wire (TXD+/-, RXD+/-) (Fullduplex)
- RS-485 - 4 wire (TXD+/-, RXD+/-) (Fullduplex)
- RS-485 - 2 wire (Data+/-, Data+/-) (Halfduplex)
- Chip-Set: SystemBase SB16C1058PCI
