| IK code | IK10 |
| International Protection (IP) code | IP67 |
| Mounting type | Ceiling/wall |
| Housing material | Metal |
| Protection features | Waterproof |
| Form factor | Bullet |
| Product colour | White |
| Power consumption (Power over Ethernet (PoE)) | 12 W |
| DC output current | 0.87 A |
| DC output voltage | 12 |
| Power source type | DC, PoE |
| Power consumption (max) | 10.5 W |
| Password reset via email | Yes |
| Password protection | Yes |
| Human and vehicle targets classification | Yes |
| Video motion detection | Yes |
| HTTPS encryption | Yes |
| Heartbeat | Yes |
| Mirror | Yes |
| IP address filtering | Yes |
| Privacy protection | Yes |
| Flash log | Yes |
| Pixel counter | Yes |
| Active tampering alarm | Yes |
| Digest authentication | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Audit log | Yes |
| Network access storage (NAS) | Yes |
| Security algorithms | TLS, HTTPS |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Web browser | Yes |
| Behavior analysis | Line crossing detection |
| Reset button | Yes |
| Web-based management | Yes |
| Height | 88.7 mm |
| Width | 93.1 mm |
| Length | 286.7 mm |
| Weight | 1.15 kg |
| Ethernet LAN | Yes |
| Number of users | 32 user(s) |
| Wi-Fi | No |
| Live view | Yes |
| Client interoperability | iVMS-4200, Hik-Connect, Hik-Central |
| Ethernet interface type | Fast Ethernet |
| Number of simultaneous live view channels | 6 channels |
| User access level | Administrator, Operator, User |
| Bluetooth | No |
| Networking standards | IEEE 802.1x, IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Languages support | Multi |
| Infrared (IR) cut-off filter | Yes |
| Dynamic range | 120 dB |
| Placement supported | Outdoor |
| Number of languages | 33 |
| Built-in light | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Package depth | 156 mm |
| Package height | 155 mm |
| Package weight | 1.64 kg |
| Package width | 386 mm |
| Number of cameras | 1 |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSDHC, MicroSDXC, MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Built-in HDD | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Camera shutter speed | 1/3 - 1/100000 s |
| Angle of rotation | 360° |
| Lens viewing angle, vertical | 55° |
| Minimum illumination | 0 lx |
| Lens viewing angle, diagonal | 127° |
| Pan range | 0 - 360° |
| Lens viewing angle, horizontal | 105° |
| Number of Privacy masking areas | 8 |
| Tilt angle range | 0 - 90° |
| Browser supported | IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ |
| Optical sensor size | 25.4 / 2.4 mm (1 / 2.4") |
| Number of sensors | 1 |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Video compression formats | H.264+, H.264, H.265, H.265+, M-JPEG |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Privacy masking | Yes |
| Gain control type | Auto |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 6 MP |
| Bit rate | 32 Kbps - 16 Mbps |
| Noise reduction technology | 3D noise reduction |
| Video recording | Yes |
| Noise reduction | Yes |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3200 x 1800, 640 x 360, 2688 x 1520, 1280 x 720 (HD 720), 640 x 480 (VGA) |
| Maximum resolution | 3200 x 1800 pixels |
| Night vision distance | 80 m |
| LED type | IR/White |
| Night vision | Yes |
| Infra-red wavelength | 850 nm |
| Number of lenses | 1 |
| Recognize distance | 15 m |
| Observe distance | 30 m |
| Maximum aperture number | 1.6 |
| Fixed focal length | 4 mm |
| Detect distance | 76 m |
| Closest focusing distance | 1.8 m |
| Identify distance | 7 m |
| Warnings | The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling. |
| Compliance certificates | RoHS, CE, WEEE, REACH, Low Voltage Directive (LVD), Federal Communications Commission (FCC) |
| Certification | FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
