| Audio input | 1 |
| Lens mount interface | M16 |
| Product colour | Black |
| International Protection (IP) code | IP67 |
| Form factor | Turret |
| Protection features | Dust resistant, Water resistant, Corrosion resistant |
| Housing material | Metal |
| Mounting type | Ceiling/Wall/Pole |
| Power consumption (max) | 16 W |
| Power source type | DC, PoE |
| DC output current | 1.34 A |
| Power consumption (Power over Ethernet (PoE)) | 18 W |
| DC output voltage | 12 |
| Security algorithms | EAP-MD5, 802.1x RADIUS, EAP-LEAP, EAP-TLS |
| Mirror | Yes |
| Password reset via email | Yes |
| Password protection | Yes |
| Digital watermark | Yes |
| Alarm input channels | 1 |
| Human and vehicle targets classification | Yes |
| Built-in siren | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Video motion detection | Yes |
| Intelligent Video Surveillance (IVS) system features | Face detection, Human detection, Line crossing detection, Region exiting detection, Vehicle detection, Region entrance detection, Scene change |
| Heartbeat | Yes |
| Alarm output channels | 1 |
| Network access storage (NAS) | Yes |
| Audit log | Yes |
| Flash log | Yes |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Active tampering alarm | Yes |
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -30 - 60 °C |
| Reset button | Yes |
| Weight | 820 g |
| Diameter | 13.8 cm |
| Height | 115.4 mm |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3at |
| Live view | Yes |
| Number of users | 32 user(s) |
| Number of simultaneous live view channels | 6 channels |
| User access level | Administrator, Operator, User |
| Built-in light | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Languages support | Multi |
| Placement supported | Indoor & outdoor |
| Dynamic range | 130 dB |
| Day/night mode | Yes |
| Number of languages | 33 |
| Infrared (IR) cut-off filter | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Package depth | 170 mm |
| Package height | 160 mm |
| Package weight | 1.2 kg |
| Package width | 170 mm |
| Number of cameras | 1 |
| Built-in microphone | Yes |
| Bit rate range | 8 - 320 Kbit/s |
| Sample rates | 8 - 48 kHz |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | G.722.1, G.711, PCM, G.726, MP3, MP2L2, AAC-LC |
| Number of microphones | 2 |
| Built-in speaker(s) | Yes |
| Compatible memory cards | MicroSDXC, MicroSD (TransFlash), MicroSDHC |
| Card reader integrated | Yes |
| Maximum memory card size | 512 GB |
| Built-in HDD | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Tilt angle range | 0 - 75° |
| Lens viewing angle, vertical | 69.9° |
| Lens viewing angle, diagonal | 123.2° |
| Lens viewing angle, horizontal | 94.5° |
| Number of Privacy masking areas | 4 |
| Angle of rotation | 360° |
| Pan range | 0 - 360° |
| Minimum illumination | 0 lx |
| Audio output | 1 |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 1280 x 720 (HD 720), 3200 x 1800, 3840 x 2160, 2688 x 1520, 640 x 360, 640 x 480 (VGA) |
| Maximum resolution | 4608 x 3456 pixels |
| Region of Interest (ROI) encoding | Yes |
| Image quality adjustment | Contrast, Saturation, Sharpness, Brightness, White balance, Gain |
| Total megapixels | 16 MP |
| Bit rate | 32 Kbps - 24 Mbps |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.265+, M-JPEG, H.264+, H.264, H.265 |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Frame rate | 30 fps |
| Highlight Compensation (HLC) | Yes |
| Noise reduction | Yes |
| Back Light Compensation (BLC) | Yes |
| Infra-red wavelength | 850 nm |
| Night vision distance | 30 m |
| Night vision | Yes |
| LED type | IR |
| Number of lenses | 1 |
| Observe distance | 46 m |
| Identify distance | 11 m |
| Detect distance | 117 m |
| Maximum aperture number | 1.6 |
| Fixed focal length | 2.8 mm |
| Recognize distance | 23 m |
| Compliance certificates | REACH, RoHS, CE, WEEE, Low Voltage Directive (LVD), Electromagnetic Compatibility (EMC), CB |
