WINDFORCE
COOLING SYSTEM
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 5 composite copper heat pipes directly touch the GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
AMD Radeon™ Anti-Lag
Minimizes input lag so you can game like a champion.
AMD Radeon™ Boost
Delivers extra performance and responsiveness when you need it most.
AMD Radeon™ Image Sharpening
Improves in-game visuals with virtually no impact to performance.
AMD Radeon™ Super Resolution
In-driver upscaler powered by FSR 1.0, elevates performance across thousands of games.In-driver upscaler powered by FSR 1.0, elevates performance across thousands of games.
AMD Noise Suppression
Reduces background audio noise from your surrounding environment for clearer communication.
AMD Link
Connect your phone, tablet, TV, or Windows-based PC and play your games from almost anywhere in the world.
| Warranty (months) | 36 |
| Packaging quantity | 1 |
| Summary | GIGABYTE GAMING Radeon RX 7600 OC 8G. Семейство графических процессоров: AMD, Графический процессор: Radeon RX 7600, Тактовая частота процессора: 2355 MHz. Объём памяти дискретного графического адаптера: 8 GB, Тип памяти графического адаптера: GDDR6, Шина памяти: 128 бит. Максимальное разрешение: 7680 x 4320 пикселей. Версия DirectX: 12 Ultimate, Версия OpenGL: 4.6. Тип интерфейса: PCI Express 4.0. Тип охлаждения: Aктивный, Количество вентиляторов: 3 вентилятор(ы), Цвет освещения: Мульти |
| Vendor Homepage | https://www.gigabyte.com/Graphics-Card/GV-R76GAMING-OC-8GD#kf |
| Category Code | VGP |
| Unit Box Height | 0.405 |
| Unit Box Length | 0.237 |
| Unit Box Width | 0.089 |
| CUDA | Нет |
| FireStream | Да |
| Processor boost clock speed (Gaming mode) | 2355 |
| Графический процессор | Radeon RX 7600 |
| Максимальное количество дисплеев на видеокарту | 4 |
| Максимальное разрешение | 7680 x 4320 |
| Потоковые процессоры | 2048 |
| Семейство графических процессоров | AMD |
| Тактовая частота процессора | 2355 |
| Тактовая частота ускорения процессора | 2755 |
| Объём памяти дискретного графического адаптера | 8 |
| Скорость передачи данных | 18 |
| Тип памяти графического адаптера | GDDR6 |
| Шина памяти | 128 |
| Версия DisplayPort | 1.4a |
| Версия HDMI | 2.1a |
| Количество HDMI портов | 2 |
| Количество USB портов С-типа | 1 |
| Количество портов DisplayPort | 2 |
| Тип интерфейса | PCI Express 4.0 |
| AMD FreeSync | Да |
| Dual Link DVI | Нет |
| Версия DirectX | 12 Ultimate |
| Версия OpenGL | 4.6 |
| Встроенный TV-тюнер | Нет |
| Высота профиля | Full-Height (FH) |
| Количество вентиляторов | 3 |
| Освещение | Да |
| Технология охлаждения | GIGABYTE WINDFORCE 3X |
| Тип охлаждения | Aктивный |
| Формат | Full-Height/Full-Length (FH/FL) |
| Цвет освещения | Мульти |
| Цвет товара | Черный |
| Дополнительные силовые разъемы | 1x 8-pin |
| Минимальное электропитание системы | 550 |
| Поддерживаемые операционные системы Windows | Windows 10 x64/Windows 11 x64 |
| Высота | 115 |
| Глубина | 50 |
| Длина | 287 |
| Тип упаковки | Коробочная версия |
| Инструкция | Да |
| Краткое руководство по установке | Да |
| Руководство пользователя | Да |
| Модель | GV-R76GAMING OC-8GD 1.1 |
| Количество в транспортной упаковке | 10 |
| Объем | 0.01002 |
| Вес без упаковки | 0.8 |
| Вес в упаковке | 1.5 |
